Description
Body
Anodized aluminum 6026
Finish
Trimless
Installation
Housing box
Power supply cable
35cm NS20N 2x0,5mm²
Power supply
Constant voltage 24Vdc
Power consumption
2W
Operating temp.
-20°C ÷ +50°C
IP rating
IP67
Insulation class
III
Weight
110g
HB.026
Housing box
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| S25.A.N.T.02 | Amber (590nm) | 10° | Trimless | 2W | Download Datasheet DS_S25ANT02_ENG |
| S25.A.W.T.02 | Amber (590nm) | 40° | Trimless | 2W | Download Datasheet DS_S25AWT02_ENG |
| S25.22.N.T.02 | 2200K | 10° | Trimless | 2W | Download Datasheet DS_S2522NT02_ENG |
| S25.22.W.T.02 | 2200K | 40° | Trimless | 2W | Download Datasheet DS_S2522WT02_ENG |
| S25.27.N.T.02 | 2700K | 10° | Trimless | 2W | Download Datasheet DS_S2527NT02_ENG |
| S25.27.W.T.02 | 2700K | 40° | Trimless | 2W | Download Datasheet DS_S2527WT02_ENG |
| S25.30.N.T.02 | 3000K | 10° | Trimless | 2W | Download Datasheet DS_S2530NT02_ENG |
| S25.30.W.T.02 | 3000K | 40° | Trimless | 2W | Download Datasheet DS_S2530WT02_ENG |
| S25.40.N.T.02 | 4000K | 10° | Trimless | 2W | Download Datasheet DS_S2540NT02_ENG |
| S25.40.W.T.02 | 4000K | 40° | Trimless | 2W | Download Datasheet DS_S2540WT02_ENG |
