Description
Body
Anodized aluminum 6026
Finish
Stainless steel AISI316L
Installation
Housing box / Fixing springs
Power supply cable
35cm NS20N 2x0,5mm² / 100cm FSC 8x0,22mm² (RGBW)
Power supply
Constant voltage 24Vdc / Constant current 4x700mA (RGBW) / Constant current 350÷14mA (Dim to Warm)
Power consumption
6W / 9W / 9W (RGBW) / 12W (Dim to Warm)
Luminous flux
386 lm / 508 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP68 (not for permanent immersion)
Insulation class
III
Weight
640g
HB.003
Housing box
HB.014
Housing box IP
ACC.114
Housing box for masonry
ACC.007
Fixing springs
ACC.004
Honeycomb louver
ACC.177
Honeycomb louver Dim to Warm
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| C8Q.22.N.03.06 | 2200K | 10° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q22N0306_ENG |
| C8Q.22.N.03.09 | 2200K | 10° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q22N0309_ENG |
| C8Q.22.M.03.06 | 2200K | 30° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q22M0306_ENG |
| C8Q.22.M.03.09 | 2200K | 30° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q22M0309_ENG |
| C8Q.22.W.03.06 | 2200K | 50° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q22W0306_ENG |
| C8Q.22.W.03.09 | 2200K | 50° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q22W0309_ENG |
| C8Q.25.N.03.06 | 2450K | 10° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q25N0306_ENG |
| C8Q.25.N.03.09 | 2450K | 10° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q25N0309_ENG |
| C8Q.25.M.03.06 | 2450K | 30° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q25M0306_ENG |
| C8Q.25.M.03.09 | 2450K | 30° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q25M0309_ENG |
| C8Q.25.W.03.06 | 2450K | 50° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q25W0306_ENG |
| C8Q.25.W.03.09 | 2450K | 50° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q25W0309_ENG |
| C8Q.27.N.03.06 | 2700K | 10° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q27N0306_ENG |
| C8Q.27.N.03.09 | 2700K | 10° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q27N0309_ENG |
| C8Q.27.M.03.06 | 2700K | 30° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q27M0306_ENG |
| C8Q.27.M.03.09 | 2700K | 30° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q27M0309_ENG |
| C8Q.27.W.03.06 | 2700K | 50° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q27W0306_ENG |
| C8Q.27.W.03.09 | 2700K | 50° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q27W0309_ENG |
| C8Q.30.N.03.06 | 3000K | 10° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q30N0306_ENG |
| C8Q.30.N.03.09 | 3000K | 10° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q30N0309_ENG |
| C8Q.30.M.03.06 | 3000K | 30° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q30M0306_ENG |
| C8Q.30.M.03.09 | 3000K | 30° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q30M0309_ENG |
| C8Q.30.W.03.06 | 3000K | 50° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q30W0306_ENG |
| C8Q.30.W.03.09 | 3000K | 50° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q30W0309_ENG |
| C8Q.40.N.03.06 | 4000K | 10° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q40N0306_ENG |
| C8Q.40.N.03.09 | 4000K | 10° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q40N0309_ENG |
| C8Q.40.M.03.06 | 4000K | 30° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q40M0306_ENG |
| C8Q.40.M.03.09 | 4000K | 30° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q40M0309_ENG |
| C8Q.40.W.03.06 | 4000K | 50° | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q40W0306_ENG |
| C8Q.40.W.03.09 | 4000K | 50° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q40W0309_ENG |
| C8Q.27.S.03.06 | 2700K | Satin | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q27S0306_ENG |
| C8Q.27.S.03.09 | 2700K | Satin | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q27S0309_ENG |
| C8Q.30.S.03.06 | 3000K | Satin | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q30S0306_ENG |
| C8Q.30.S.03.09 | 3000K | Satin | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q30S0309_ENG |
| C8Q.40.S.03.06 | 4000K | Satin | Stainless steel AISI316L | 6W | Download Datasheet DS_C8Q40S0306_ENG |
| C8Q.40.S.03.09 | 4000K | Satin | Stainless steel AISI316L | 9W | Download Datasheet DS_C8Q40S0309_ENG |
| C8Q.FC.M.03.CC | RGBW | 30° | Stainless steel AISI316L | 9W | Download Datasheet DS_C8QFCM03CC_ENG |
| C8Q.DW.M.03.CC | Dim to Warm (1800K÷3000K) | 20° | Stainless steel AISI316L | 12W | Download Datasheet DS_C8QDWM03CC_ENG |
| C8Q.DW.W.03.CC | Dim to Warm (1800K÷3000K) | 50° | Stainless steel AISI316L | 12W | Download Datasheet DS_C8QDWW03CC_ENG |
