Description
Body
Anodized aluminum 6026
Finish
Stainless steel AISI316L / Aged solid brass / Pre-aged solid brass
Installation
Housing box / Fixing springs
Power supply cable
35cm NS20N 2x0,5mm²
Power supply
Constant voltage 24Vdc
Power consumption
2W
Luminous flux
94 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP68 (not for permanent immersion)
Insulation class
III
Weight
280g
HB.002
Housing box
HB.013
Housing box IP
ACC.114
Housing box for masonry
ACC.006
Fixing springs
ACC.084
Honeycomb louver
ACC.008
Anti-Glare louver
ACC.089
Anti-Glare louver closed
ACC.083
Anti-Glare louver for honeycomb louver
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| C52.A.N.03.02 | Amber (590nm) | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_C52AN0302_ENG |
| C52.A.N.10.02 | Amber (590nm) | 10° | Aged solid brass | 2W | Download Datasheet DS_C52AN1002_ENG |
| C52.A.N.21.02 | Amber (590nm) | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_C52AN2102_ENG |
| C52.A.M.03.02 | Amber (590nm) | 23° | Stainless steel AISI316L | 2W | Download Datasheet DS_C52AM0302_ENG |
| C52.A.M.10.02 | Amber (590nm) | 23° | Aged solid brass | 2W | Download Datasheet DS_C52AM1002_ENG |
| C52.A.M.21.02 | Amber (590nm) | 23° | Pre-aged solid brass | 2W | Download Datasheet DS_C52AM2102_ENG |
| C52.A.W.03.02 | Amber (590nm) | 43° | Stainless steel AISI316L | 2W | Download Datasheet DS_C52AW0302_ENG |
| C52.A.W.10.02 | Amber (590nm) | 43° | Aged solid brass | 2W | Download Datasheet DS_C52AW1002_ENG |
| C52.A.W.21.02 | Amber (590nm) | 43° | Pre-aged solid brass | 2W | Download Datasheet DS_C52AW2102_ENG |
| C52.A.E.03.02 | Amber (590nm) | 10°x40° | Stainless steel AISI316L | 2W | Download Datasheet DS_C52AE0302_ENG |
| C52.A.E.10.02 | Amber (590nm) | 10°x40° | Aged solid brass | 2W | Download Datasheet DS_C52AE1002_ENG |
| C52.A.E.21.02 | Amber (590nm) | 10°x40° | Pre-aged solid brass | 2W | Download Datasheet DS_C52AE2102_ENG |
| C52.22.N.03.02 | 2200K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5222N0302_ENG |
| C52.22.N.10.02 | 2200K | 10° | Aged solid brass | 2W | Download Datasheet DS_C5222N1002_ENG |
| C52.22.N.21.02 | 2200K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_C5222N2102_ENG |
| C52.22.M.03.02 | 2200K | 23° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5222M0302_ENG |
| C52.22.M.10.02 | 2200K | 23° | Aged solid brass | 2W | Download Datasheet DS_C5222M1002_ENG |
| C52.22.M.21.02 | 2200K | 23° | Pre-aged solid brass | 2W | Download Datasheet DS_C5222M2102_ENG |
| C52.22.W.03.02 | 2200K | 43° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5222W0302_ENG |
| C52.22.W.10.02 | 2200K | 43° | Aged solid brass | 2W | Download Datasheet DS_C5222W1002_ENG |
| C52.22.W.21.02 | 2200K | 43° | Pre-aged solid brass | 2W | Download Datasheet DS_C5222W2102_ENG |
| C52.22.E.03.02 | 2200K | 10°x40° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5222E0302_ENG |
| C52.22.E.10.02 | 2200K | 10°x40° | Aged solid brass | 2W | Download Datasheet DS_C5222E1002_ENG |
| C52.22.E.21.02 | 2200K | 10°x40° | Pre-aged solid brass | 2W | Download Datasheet DS_C5222E2102_ENG |
| C52.25.N.03.02 | 2450K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5225N0302_ENG |
| C52.25.N.10.02 | 2450K | 10° | Aged solid brass | 2W | Download Datasheet DS_C5225N1002_ENG |
| C52.25.N.21.02 | 2450K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_C5225N2102_ENG |
| C52.25.M.03.02 | 2450K | 23° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5225M0302_ENG |
| C52.25.M.10.02 | 2450K | 23° | Aged solid brass | 2W | Download Datasheet DS_C5225M1002_ENG |
| C52.25.M.21.02 | 2450K | 23° | Pre-aged solid brass | 2W | Download Datasheet DS_C5225M2102_ENG |
| C52.25.W.03.02 | 2450K | 43° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5225W0302_ENG |
| C52.25.W.10.02 | 2450K | 43° | Aged solid brass | 2W | Download Datasheet DS_C5225W1002_ENG |
| C52.25.W.21.02 | 2450K | 43° | Pre-aged solid brass | 2W | Download Datasheet DS_C5225W2102_ENG |
| C52.25.E.03.02 | 2450K | 10°x40° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5225E0302_ENG |
| C52.25.E.10.02 | 2450K | 10°x40° | Aged solid brass | 2W | Download Datasheet DS_C5225E1002_ENG |
| C52.25.E.21.02 | 2450K | 10°x40° | Pre-aged solid brass | 2W | Download Datasheet DS_C5225E2102_ENG |
| C52.27.N.03.02 | 2700K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5227N0302_ENG |
| C52.27.N.10.02 | 2700K | 10° | Aged solid brass | 2W | Download Datasheet DS_C5227N1002_ENG |
| C52.27.N.21.02 | 2700K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_C5227N2102_ENG |
| C52.27.M.03.02 | 2700K | 23° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5227M0302_ENG |
| C52.27.M.10.02 | 2700K | 23° | Aged solid brass | 2W | Download Datasheet DS_C5227M1002_ENG |
| C52.27.M.21.02 | 2700K | 23° | Pre-aged solid brass | 2W | Download Datasheet DS_C5227M2102_ENG |
| C52.27.W.03.02 | 2700K | 43° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5227W0302_ENG |
| C52.27.W.10.02 | 2700K | 43° | Aged solid brass | 2W | Download Datasheet DS_C5227W1002_ENG |
| C52.27.W.21.02 | 2700K | 43° | Pre-aged solid brass | 2W | Download Datasheet DS_C5227W2102_ENG |
| C52.27.E.03.02 | 2700K | 10°x40° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5227E0302_ENG |
| C52.27.E.10.02 | 2700K | 10°x40° | Aged solid brass | 2W | Download Datasheet DS_C5227E1002_ENG |
| C52.27.E.21.02 | 2700K | 10°x40° | Pre-aged solid brass | 2W | Download Datasheet DS_C5227E2102_ENG |
| C52.30.N.03.02 | 3000K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5230N0302_ENG |
| C52.30.N.10.02 | 3000K | 10° | Aged solid brass | 2W | Download Datasheet DS_C5230N1002_ENG |
| C52.30.N.21.02 | 3000K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_C5230N2102_ENG |
| C52.30.M.03.02 | 3000K | 23° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5230M0302_ENG |
| C52.30.M.10.02 | 3000K | 23° | Aged solid brass | 2W | Download Datasheet DS_C5230M1002_ENG |
| C52.30.M.21.02 | 3000K | 23° | Pre-aged solid brass | 2W | Download Datasheet DS_C5230M2102_ENG |
| C52.30.W.03.02 | 3000K | 43° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5230W0302_ENG |
| C52.30.W.10.02 | 3000K | 43° | Aged solid brass | 2W | Download Datasheet DS_C5230W1002_ENG |
| C52.30.W.21.02 | 3000K | 43° | Pre-aged solid brass | 2W | Download Datasheet DS_C5230W2102_ENG |
| C52.30.E.03.02 | 3000K | 10°x40° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5230E0302_ENG |
| C52.30.E.10.02 | 3000K | 10°x40° | Aged solid brass | 2W | Download Datasheet DS_C5230E1002_ENG |
| C52.30.E.21.02 | 3000K | 10°x40° | Pre-aged solid brass | 2W | Download Datasheet DS_C5230E2102_ENG |
| C52.40.N.03.02 | 4000K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5240N0302_ENG |
| C52.40.N.10.02 | 4000K | 10° | Aged solid brass | 2W | Download Datasheet DS_C5240N1002_ENG |
| C52.40.N.21.02 | 4000K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_C5240N2102_ENG |
| C52.40.M.03.02 | 4000K | 23° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5240M0302_ENG |
| C52.40.M.10.02 | 4000K | 23° | Aged solid brass | 2W | Download Datasheet DS_C5240M1002_ENG |
| C52.40.M.21.02 | 4000K | 23° | Pre-aged solid brass | 2W | Download Datasheet DS_C5240M2102_ENG |
| C52.40.W.03.02 | 4000K | 43° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5240W0302_ENG |
| C52.40.W.10.02 | 4000K | 43° | Aged solid brass | 2W | Download Datasheet DS_C5240W1002_ENG |
| C52.40.W.21.02 | 4000K | 43° | Pre-aged solid brass | 2W | Download Datasheet DS_C5240W2102_ENG |
| C52.40.E.03.02 | 4000K | 10°x40° | Stainless steel AISI316L | 2W | Download Datasheet DS_C5240E0302_ENG |
| C52.40.E.10.02 | 4000K | 10°x40° | Aged solid brass | 2W | Download Datasheet DS_C5240E1002_ENG |
| C52.40.E.21.02 | 4000K | 10°x40° | Pre-aged solid brass | 2W | Download Datasheet DS_C5240E2102_ENG |
| C52.A.S.03.02 | Amber (590nm) | Satin | Stainless steel AISI316L | 2W | Download Datasheet DS_C52AS0302_ENG |
| C52.A.S.10.02 | Amber (590nm) | Satin | Aged solid brass | 2W | Download Datasheet DS_C52AS1002_ENG |
| C52.A.S.21.02 | Amber (590nm) | Satin | Pre-aged solid brass | 2W | Download Datasheet DS_C52AS2102_ENG |
| C52.22.S.03.02 | 2200K | Satin | Stainless steel AISI316L | 2W | Download Datasheet DS_C5222S0302_ENG |
| C52.22.S.10.02 | 2200K | Satin | Aged solid brass | 2W | Download Datasheet DS_C5222S1002_ENG |
| C52.22.S.21.02 | 2200K | Satin | Pre-aged solid brass | 2W | Download Datasheet DS_C5222S2102_ENG |
| C52.27.S.03.02 | 2700K | Satin | Stainless steel AISI316L | 2W | Download Datasheet DS_C5227S0302_ENG |
| C52.27.S.10.02 | 2700K | Satin | Aged solid brass | 2W | Download Datasheet DS_C5227S1002_ENG |
| C52.27.S.21.02 | 2700K | Satin | Pre-aged solid brass | 2W | Download Datasheet DS_C5227S2102_ENG |
| C52.30.S.03.02 | 3000K | Satin | Stainless steel AISI316L | 2W | Download Datasheet DS_C5230S0302_ENG |
| C52.30.S.10.02 | 3000K | Satin | Aged solid brass | 2W | Download Datasheet DS_C5230S1002_ENG |
| C52.30.S.21.02 | 3000K | Satin | Pre-aged solid brass | 2W | Download Datasheet DS_C5230S2102_ENG |
| C52.40.S.03.02 | 4000K | Satin | Stainless steel AISI316L | 2W | Download Datasheet DS_C5240S0302_ENG |
| C52.40.S.10.02 | 4000K | Satin | Aged solid brass | 2W | Download Datasheet DS_C5240S1002_ENG |
| C52.40.S.21.02 | 4000K | Satin | Pre-aged solid brass | 2W | Download Datasheet DS_C5240S2102_ENG |
| C52.A.A.03.02 | Amber (590nm) | Asymmetric | Stainless steel AISI316L | 2W | Download Datasheet DS_C52AA0302_ENG |
| C52.A.A.10.02 | Amber (590nm) | Asymmetric | Aged solid brass | 2W | Download Datasheet DS_C52AA1002_ENG |
| C52.A.A.21.02 | Amber (590nm) | Asymmetric | Pre-aged solid brass | 2W | Download Datasheet DS_C52AA2102_ENG |
| C52.22.A.03.02 | 2200K | Asymmetric | Stainless steel AISI316L | 2W | Download Datasheet DS_C5222A0302_ENG |
| C52.22.A.10.02 | 2200K | Asymmetric | Aged solid brass | 2W | Download Datasheet DS_C5222A1002_ENG |
| C52.22.A.21.02 | 2200K | Asymmetric | Pre-aged solid brass | 2W | Download Datasheet DS_C5222A2102_ENG |
| C52.25.A.03.02 | 2450K | Asymmetric | Stainless steel AISI316L | 2W | Download Datasheet DS_C5225A0302_ENG |
| C52.25.A.10.02 | 2450K | Asymmetric | Aged solid brass | 2W | Download Datasheet DS_C5225A1002_ENG |
| C52.25.A.21.02 | 2450K | Asymmetric | Pre-aged solid brass | 2W | Download Datasheet DS_C5225A2102_ENG |
| C52.27.A.03.02 | 2700K | Asymmetric | Stainless steel AISI316L | 2W | Download Datasheet DS_C5227A0302_ENG |
| C52.27.A.10.02 | 2700K | Asymmetric | Aged solid brass | 2W | Download Datasheet DS_C5227A1002_ENG |
| C52.27.A.21.02 | 2700K | Asymmetric | Pre-aged solid brass | 2W | Download Datasheet DS_C5227A2102_ENG |
| C52.30.A.03.02 | 3000K | Asymmetric | Stainless steel AISI316L | 2W | Download Datasheet DS_C5230A0302_ENG |
| C52.30.A.10.02 | 3000K | Asymmetric | Aged solid brass | 2W | Download Datasheet DS_C5230A1002_ENG |
| C52.30.A.21.02 | 3000K | Asymmetric | Pre-aged solid brass | 2W | Download Datasheet DS_C5230A2102_ENG |
| C52.40.A.03.02 | 4000K | Asymmetric | Stainless steel AISI316L | 2W | Download Datasheet DS_C5240A0302_ENG |
| C52.40.A.10.02 | 4000K | Asymmetric | Aged solid brass | 2W | Download Datasheet DS_C5240A1002_ENG |
| C52.40.A.21.02 | 4000K | Asymmetric | Pre-aged solid brass | 2W | Download Datasheet DS_C5240A2102_ENG |
