Description
Body
Anodized aluminum 6026
Finish
Stone-washed AISI316L stainless steel / Antique brass / Pre-anodized brass
Installation
Housing box
Power supply cable
35cm NS20N 2x0,5mm²
Power supply
Constant voltage 24Vdc
Power consumption
6W / 9W
Luminous flux
163 lm / 219 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP68 (not for permanent immersion)
Insulation class
III
Weight
1200g
HB.012
Housing box
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| E125-1.27.R.10.06 | 2700K | 90° | Aged solid brass | 6W | Download Datasheet DS_E125-127R1006_ENG |
| E125-1.27.R.10.09 | 2700K | 90° | Aged solid brass | 9W | Download Datasheet DS_E125-127R1009_ENG |
| E125-1.27.R.17.06 | 2700K | 90° | Stone washed stainless steel AISI316L | 6W | Download Datasheet DS_E125-127R1706_ENG |
| E125-1.27.R.17.09 | 2700K | 90° | Stone washed stainless steel AISI316L | 9W | Download Datasheet DS_E125-127R1709_ENG |
| E125-1.27.R.21.06 | 2700K | 90° | Pre-aged solid brass | 6W | Download Datasheet DS_E125-127R2106_ENG |
| E125-1.27.R.21.09 | 2700K | 90° | Pre-aged solid brass | 9W | Download Datasheet DS_E125-127R2109_ENG |
| E125-1.30.R.10.06 | 3000K | 90° | Aged solid brass | 6W | Download Datasheet DS_E125-130R1006_ENG |
| E125-1.30.R.10.09 | 3000K | 90° | Aged solid brass | 9W | Download Datasheet DS_E125-130R1009_ENG |
| E125-1.30.R.17.06 | 3000K | 90° | Stone washed stainless steel AISI316L | 6W | Download Datasheet DS_E125-130R1706_ENG |
| E125-1.30.R.17.09 | 3000K | 90° | Stone washed stainless steel AISI316L | 9W | Download Datasheet DS_E125-130R1709_ENG |
| E125-1.30.R.21.06 | 3000K | 90° | Pre-aged solid brass | 6W | Download Datasheet DS_E125-130R2106_ENG |
| E125-1.30.R.21.09 | 3000K | 90° | Pre-aged solid brass | 9W | Download Datasheet DS_E125-130R2109_ENG |
| E125-1.40.R.10.06 | 4000K | 90° | Aged solid brass | 6W | Download Datasheet DS_E125-140R1006_ENG |
| E125-1.40.R.10.09 | 4000K | 90° | Aged solid brass | 9W | Download Datasheet DS_E125-140R1009_ENG |
| E125-1.40.R.17.06 | 4000K | 90° | Stone washed stainless steel AISI316L | 6W | Download Datasheet DS_E125-140R1706_ENG |
| E125-1.40.R.17.09 | 4000K | 90° | Stone washed stainless steel AISI316L | 9W | Download Datasheet DS_E125-140R1709_ENG |
| E125-1.40.R.21.06 | 4000K | 90° | Pre-aged solid brass | 6W | Download Datasheet DS_E125-140R2106_ENG |
| E125-1.40.R.21.09 | 4000K | 90° | Pre-aged solid brass | 9W | Download Datasheet DS_E125-140R2109_ENG |
