Description
Body
Anodized aluminum 6026
Finish
Stone washed stainless steel AISI316L / Aged solid brass / Pre-aged solid brass
Installation
Housing box / Fixing springs
Power supply cable
35cm NS20N 2x0,5mm²
Power supply
Constant voltage 24Vdc
Power consumption
2W
Luminous flux
15 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP68 (not for permanent immersion)
Insulation class
III
Weight
241g
HB.009
Housing box
ACC.050
Fixing springs
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| E65-1.A.R.10.02 | Amber (590nm) | 90° | Aged solid brass | 2W | Download Datasheet DS_E65-1AR1002_ENG |
| E65-1.A.R.17.02 | Amber (590nm) | 90° | Stone washed stainless steel AISI316L | 2W | Download Datasheet DS_E65-1AR1702_ENG |
| E65-1.A.R.21.02 | Amber (590nm) | 90° | Pre-aged solid brass | 2W | Download Datasheet DS_E65-1AR2102_ENG |
| E65-1.22.R.10.02 | 2200K | 90° | Aged solid brass | 2W | Download Datasheet DS_E65-122R1002_ENG |
| E65-1.22.R.17.02 | 2200K | 90° | Stone washed stainless steel AISI316L | 2W | Download Datasheet DS_E65-122R1702_ENG |
| E65-1.22.R.21.02 | 2200K | 90° | Pre-aged solid brass | 2W | Download Datasheet DS_E65-122R2102_ENG |
| E65-1.27.R.10.02 | 2700K | 90° | Aged solid brass | 2W | Download Datasheet DS_E65-127R1002_ENG |
| E65-1.27.R.17.02 | 2700K | 90° | Stone washed stainless steel AISI316L | 2W | Download Datasheet DS_E65-127R1702_ENG |
| E65-1.27.R.21.02 | 2700K | 90° | Pre-aged solid brass | 2W | Download Datasheet DS_E65-127R2102_ENG |
| E65-1.30.R.10.02 | 3000K | 90° | Aged solid brass | 2W | Download Datasheet DS_E65-130R1002_ENG |
| E65-1.30.R.17.02 | 3000K | 90° | Stone washed stainless steel AISI316L | 2W | Download Datasheet DS_E65-130R1702_ENG |
| E65-1.30.R.21.02 | 3000K | 90° | Pre-aged solid brass | 2W | Download Datasheet DS_E65-130R2102_ENG |
| E65-1.40.R.10.02 | 4000K | 90° | Aged solid brass | 2W | Download Datasheet DS_E65-140R1002_ENG |
| E65-1.40.R.17.02 | 4000K | 90° | Stone washed stainless steel AISI316L | 2W | Download Datasheet DS_E65-140R1702_ENG |
| E65-1.40.R.21.02 | 4000K | 90° | Pre-aged solid brass | 2W | Download Datasheet DS_E65-140R2102_ENG |
