Description
Body
Anodized aluminum 6026
Finish
Stainless steel AISI316L / Aged solid brass / Pre-aged solid brass
Installation
Housing box / Fixing springs
Power supply cable
35cm NS20N 2x0,5mm²
Power supply
Constant voltage 24Vdc
Power consumption
2W
Luminous flux
53 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP68 (not for permanent immersion)
Insulation class
III
Weight
208g
HB.002
Housing box
HB.013
Housing box IP
ACC.050
Fixing springs
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| CWQ.A.N.03.02 | Amber (590nm) | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQAN0302_ENG |
| CWQ.A.N.10.02 | Amber (590nm) | 10° | Aged solid brass | 2W | Download Datasheet DS_CWQAN1002_ENG |
| CWQ.A.N.21.02 | Amber (590nm) | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQAN2102_ENG |
| CWQ.A.W.03.02 | Amber (590nm) | 40° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQAW0302_ENG |
| CWQ.A.W.10.02 | Amber (590nm) | 40° | Aged solid brass | 2W | Download Datasheet DS_CWQAW1002_ENG |
| CWQ.A.W.21.02 | Amber (590nm) | 40° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQAW2102_ENG |
| CWQ.22.N.03.02 | 2200K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ22N0302_ENG |
| CWQ.22.N.10.02 | 2200K | 10° | Aged solid brass | 2W | Download Datasheet DS_CWQ22N1002_ENG |
| CWQ.22.N.21.02 | 2200K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ22N2102_ENG |
| CWQ.22.W.03.02 | 2200K | 40° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ22W0302_ENG |
| CWQ.22.W.10.02 | 2200K | 40° | Aged solid brass | 2W | Download Datasheet DS_CWQ22W1002_ENG |
| CWQ.22.W.21.02 | 2200K | 40° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ22W2102_ENG |
| CWQ.27.N.03.02 | 2700K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ27N0302_ENG |
| CWQ.27.N.10.02 | 2700K | 10° | Aged solid brass | 2W | Download Datasheet DS_CWQ27N1002_ENG |
| CWQ.27.N.21.02 | 2700K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ27N2102_ENG |
| CWQ.27.W.03.02 | 2700K | 40° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ27W0302_ENG |
| CWQ.27.W.10.02 | 2700K | 40° | Aged solid brass | 2W | Download Datasheet DS_CWQ27W1002_ENG |
| CWQ.27.W.21.02 | 2700K | 40° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ27W2102_ENG |
| CWQ.30.N.03.02 | 3000K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ30N0302_ENG |
| CWQ.30.N.10.02 | 3000K | 10° | Aged solid brass | 2W | Download Datasheet DS_CWQ30N1002_ENG |
| CWQ.30.N.21.02 | 3000K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ30N2102_ENG |
| CWQ.30.W.03.02 | 3000K | 40° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ30W0302_ENG |
| CWQ.30.W.10.02 | 3000K | 40° | Aged solid brass | 2W | Download Datasheet DS_CWQ30W1002_ENG |
| CWQ.30.W.21.02 | 3000K | 40° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ30W2102_ENG |
| CWQ.40.N.03.02 | 4000K | 10° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ40N0302_ENG |
| CWQ.40.N.10.02 | 4000K | 10° | Aged solid brass | 2W | Download Datasheet DS_CWQ40N1002_ENG |
| CWQ.40.N.21.02 | 4000K | 10° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ40N2102_ENG |
| CWQ.40.W.03.02 | 4000K | 40° | Stainless steel AISI316L | 2W | Download Datasheet DS_CWQ40W0302_ENG |
| CWQ.40.W.10.02 | 4000K | 40° | Aged solid brass | 2W | Download Datasheet DS_CWQ40W1002_ENG |
| CWQ.40.W.21.02 | 4000K | 40° | Pre-aged solid brass | 2W | Download Datasheet DS_CWQ40W2102_ENG |
