Description
Body
Anodized aluminum 6026
Finish
Stainless steel AISI316L / Aged solid brass / Pre-aged solid brass
Installation
Housing box
Power supply cable
35cm NS20N 2x0,5mm² / 100cm FSC 8x0,22mm² (RGBW)
Power supply
Constant voltage 24Vdc / Constant current 4x700mA (RGBW)
Power consumption
6W / 9W / 9W (RGBW)
Luminous flux
347 lm / 443 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP67
Insulation class
III
Weight
900g
HB.011
Housing box
HB.011.200
Housing box 200mm
ACC.119
Honeycomb louver
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP68
ACC.225
Pre-assembled male connector on product – IP68
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| C120D.22.N.03.06 | 2200K | 10° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D22N0306_ENG |
| C120D.22.N.03.09 | 2200K | 10° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D22N0309_ENG |
| C120D.22.N.10.06 | 2200K | 10° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D22N1006_ENG |
| C120D.22.N.10.09 | 2200K | 10° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D22N1009_ENG |
| C120D.22.N.21.06 | 2200K | 10° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D22N2106_ENG |
| C120D.22.N.21.09 | 2200K | 10° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D22N2109_ENG |
| C120D.22.M.03.06 | 2200K | 35° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D22M0306_ENG |
| C120D.22.M.03.09 | 2200K | 35° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D22M0309_ENG |
| C120D.22.M.10.06 | 2200K | 35° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D22M1006_ENG |
| C120D.22.M.10.09 | 2200K | 35° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D22M1009_ENG |
| C120D.22.M.21.06 | 2200K | 35° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D22M2106_ENG |
| C120D.22.M.21.09 | 2200K | 35° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D22M2109_ENG |
| C120D.22.W.03.06 | 2200K | 50° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D22W0306_ENG |
| C120D.22.W.03.09 | 2200K | 50° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D22W0309_ENG |
| C120D.22.W.10.06 | 2200K | 50° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D22W1006_ENG |
| C120D.22.W.10.09 | 2200K | 50° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D22W1009_ENG |
| C120D.22.W.21.06 | 2200K | 50° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D22W2106_ENG |
| C120D.22.W.21.09 | 2200K | 50° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D22W2109_ENG |
| C120D.25.N.03.06 | 2450K | 10° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D25N0306_ENG |
| C120D.25.N.03.09 | 2450K | 10° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D25N0309_ENG |
| C120D.25.N.10.06 | 2450K | 10° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D25N1006_ENG |
| C120D.25.N.10.09 | 2450K | 10° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D25N1009_ENG |
| C120D.25.N.21.06 | 2450K | 10° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D25N2106_ENG |
| C120D.25.N.21.09 | 2450K | 10° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D25N2109_ENG |
| C120D.25.M.03.06 | 2450K | 35° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D25M0306_ENG |
| C120D.25.M.03.09 | 2450K | 35° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D25M0309_ENG |
| C120D.25.M.10.06 | 2450K | 35° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D25M1006_ENG |
| C120D.25.M.10.09 | 2450K | 35° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D25M1009_ENG |
| C120D.25.M.21.06 | 2450K | 35° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D25M2106_ENG |
| C120D.25.M.21.09 | 2450K | 35° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D25M2109_ENG |
| C120D.25.W.03.06 | 2450K | 50° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D25W0306_ENG |
| C120D.25.W.03.09 | 2450K | 50° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D25W0309_ENG |
| C120D.25.W.10.06 | 2450K | 50° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D25W1006_ENG |
| C120D.25.W.10.09 | 2450K | 50° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D25W1009_ENG |
| C120D.25.W.21.06 | 2450K | 50° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D25W2106_ENG |
| C120D.25.W.21.09 | 2450K | 50° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D25W2109_ENG |
| C120D.27.N.03.06 | 2700K | 10° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D27N0306_ENG |
| C120D.27.N.03.09 | 2700K | 10° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D27N0309_ENG |
| C120D.27.N.10.06 | 2700K | 10° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D27N1006_ENG |
| C120D.27.N.10.09 | 2700K | 10° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D27N1009_ENG |
| C120D.27.N.21.06 | 2700K | 10° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D27N2106_ENG |
| C120D.27.N.21.09 | 2700K | 10° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D27N2109_ENG |
| C120D.27.M.03.06 | 2700K | 35° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D27M0306_ENG |
| C120D.27.M.03.09 | 2700K | 35° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D27M0309_ENG |
| C120D.27.M.10.06 | 2700K | 35° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D27M1006_ENG |
| C120D.27.M.10.09 | 2700K | 35° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D27M1009_ENG |
| C120D.27.M.21.06 | 2700K | 35° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D27M2106_ENG |
| C120D.27.M.21.09 | 2700K | 35° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D27M2109_ENG |
| C120D.27.W.03.06 | 2700K | 50° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D27W0306_ENG |
| C120D.27.W.03.09 | 2700K | 50° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D27W0309_ENG |
| C120D.27.W.10.06 | 2700K | 50° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D27W1006_ENG |
| C120D.27.W.10.09 | 2700K | 50° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D27W1009_ENG |
| C120D.27.W.21.06 | 2700K | 50° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D27W2106_ENG |
| C120D.27.W.21.09 | 2700K | 50° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D27W2109_ENG |
| C120D.30.N.03.06 | 3000K | 10° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D30N0306_ENG |
| C120D.30.N.03.09 | 3000K | 10° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D30N0309_ENG |
| C120D.30.N.10.06 | 3000K | 10° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D30N1006_ENG |
| C120D.30.N.10.09 | 3000K | 10° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D30N1009_ENG |
| C120D.30.N.21.06 | 3000K | 10° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D30N2106_ENG |
| C120D.30.N.21.09 | 3000K | 10° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D30N2109_ENG |
| C120D.30.M.03.06 | 3000K | 35° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D30M0306_ENG |
| C120D.30.M.03.09 | 3000K | 35° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D30M0309_ENG |
| C120D.30.M.10.06 | 3000K | 35° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D30M1006_ENG |
| C120D.30.M.10.09 | 3000K | 35° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D30M1009_ENG |
| C120D.30.M.21.06 | 3000K | 35° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D30M2106_ENG |
| C120D.30.M.21.09 | 3000K | 35° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D30M2109_ENG |
| C120D.30.W.03.06 | 3000K | 50° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D30W0306_ENG |
| C120D.30.W.03.09 | 3000K | 50° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D30W0309_ENG |
| C120D.30.W.10.06 | 3000K | 50° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D30W1006_ENG |
| C120D.30.W.10.09 | 3000K | 50° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D30W1009_ENG |
| C120D.30.W.21.06 | 3000K | 50° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D30W2106_ENG |
| C120D.30.W.21.09 | 3000K | 50° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D30W2109_ENG |
| C120D.40.N.03.06 | 4000K | 10° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D40N0306_ENG |
| C120D.40.N.03.09 | 4000K | 10° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D40N0309_ENG |
| C120D.40.N.10.06 | 4000K | 10° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D40N1006_ENG |
| C120D.40.N.10.09 | 4000K | 10° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D40N1009_ENG |
| C120D.40.N.21.06 | 4000K | 10° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D40N2106_ENG |
| C120D.40.N.21.09 | 4000K | 10° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D40N2109_ENG |
| C120D.40.M.03.06 | 4000K | 35° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D40M0306_ENG |
| C120D.40.M.03.09 | 4000K | 35° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D40M0309_ENG |
| C120D.40.M.10.06 | 4000K | 35° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D40M1006_ENG |
| C120D.40.M.10.09 | 4000K | 35° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D40M1009_ENG |
| C120D.40.M.21.06 | 4000K | 35° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D40M2106_ENG |
| C120D.40.M.21.09 | 4000K | 35° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D40M2109_ENG |
| C120D.40.W.03.06 | 4000K | 50° adjustable ±15° | Stainless steel AISI316L | 6W | Download Datasheet DS_C120D40W0306_ENG |
| C120D.40.W.03.09 | 4000K | 50° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120D40W0309_ENG |
| C120D.40.W.10.06 | 4000K | 50° adjustable ±15° | Aged solid brass | 6W | Download Datasheet DS_C120D40W1006_ENG |
| C120D.40.W.10.09 | 4000K | 50° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120D40W1009_ENG |
| C120D.40.W.21.06 | 4000K | 50° adjustable ±15° | Pre-aged solid brass | 6W | Download Datasheet DS_C120D40W2106_ENG |
| C120D.40.W.21.09 | 4000K | 50° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120D40W2109_ENG |
| C120D.FC.M.03.CC | RGBW | 35° adjustable ±15° | Stainless steel AISI316L | 9W | Download Datasheet DS_C120DFCM03CC_ENG |
| C120D.FC.M.10.CC | RGBW | 35° adjustable ±15° | Aged solid brass | 9W | Download Datasheet DS_C120DFCM10CC_ENG |
| C120D.FC.M.21.CC | RGBW | 35° adjustable ±15° | Pre-aged solid brass | 9W | Download Datasheet DS_C120DFCM21CC_ENG |
