Description
Body
Stainless steel AISI316L
Finish
Electropolished Stainless Steel AISI316L
Installation
Housing box
Power supply cable
500cm NS20N 2x0,5mm² / 500cm NTQ0N 4x0,5mm² (RGB)
Power supply
Constant voltage 24Vdc / Constant voltage 12Vdc (RGB)
Power consumption
2W / 1,3W (RGB)
Luminous flux
136 lm (3000K)
Operating temp.
-20°C ÷ +50°C
IP rating
IP68 (5 meter underwater)
Insulation class
III
Weight
210g
HB.018
Housing box
ACC.190
Honeycomb louver
ACC.187
Anti-Glare louver
ACC.188
Anti-Glare louver 50%
ACC.189
Anti-Glare louver 70%
ACC.200
Fixing springs
ACC.101
Micro junction connection 3-way 2M+1F 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP69K
ACC.127
Micro joint connection 10A 2-pole 0,25–1,5mm² Øcable 5,8–6,9mm – IP69K
ACC.225
Pre-assembled male connector on product – IP69K
CV00037
Cable 5m
CV00040
Cable 10m
CV00041
Cable 15m
CV00042
Cable 20m
CV00043
Cable 25m
Generate datasheet
| Code | Color temperature | Optic | Finishing | Power | Datasheet |
|---|---|---|---|---|---|
| C3S.22.N.12.02 | 2200K | 10° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S22N1202_ENG |
| C3S.22.M.12.02 | 2200K | 20° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S22M1202_ENG |
| C3S.22.W.12.02 | 2200K | 41° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S22W1202_ENG |
| C3S.22.E.12.02 | 2200K | 10°x45° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S22E1202_ENG |
| C3S.22.S.12.02 | 2200K | Satin | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S22S1202_ENG |
| C3S.27.N.12.02 | 2700K | 10° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S27N1202_ENG |
| C3S.27.M.12.02 | 2700K | 20° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S27M1202_ENG |
| C3S.27.W.12.02 | 2700K | 41° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S27W1202_ENG |
| C3S.27.E.12.02 | 2700K | 10°x45° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S27E1202_ENG |
| C3S.27.S.12.02 | 2700K | Satin | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S27S1202_ENG |
| C3S.30.N.12.02 | 3000K | 10° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S30N1202_ENG |
| C3S.30.M.12.02 | 3000K | 20° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S30M1202_ENG |
| C3S.30.W.12.02 | 3000K | 41° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S30W1202_ENG |
| C3S.30.E.12.02 | 3000K | 10°x45° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S30E1202_ENG |
| C3S.30.S.12.02 | 3000K | Satin | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S30S1202_ENG |
| C3S.40.N.12.02 | 4000K | 10° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S40N1202_ENG |
| C3S.40.M.12.02 | 4000K | 20° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S40M1202_ENG |
| C3S.40.W.12.02 | 4000K | 41° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S40W1202_ENG |
| C3S.40.E.12.02 | 4000K | 10°x45° | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S40E1202_ENG |
| C3S.40.S.12.02 | 4000K | Satin | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S40S1202_ENG |
| C3S.22.A.12.02 | 2200K | Asymmetric | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S22A1202_ENG |
| C3S.27.A.12.02 | 2700K | Asymmetric | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S27A1202_ENG |
| C3S.30.A.12.02 | 3000K | Asymmetric | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S30A1202_ENG |
| C3S.40.A.12.02 | 4000K | Asymmetric | Electropolished Stainless Steel AISI316L | 2W | Download Datasheet DS_C3S40A1202_ENG |
| C3S.RGB.O.12.02 | RGB | Opal | Electropolished Stainless Steel AISI316L | 1,3W | Download Datasheet DS_C3SRGBO1202_ENG |
